Feeding, Crushing and Conveying Integrated Machine

The fertilizer feeding, crushing, and conveying integrated machine is a multifunctional piece of equipment designed to streamline the processing of bulk fertilizers. It combines feeding, crushing, and conveying into a single system, significantly improving efficiency and reducing labor costs.

The machine is capable of handling various types of fertilizers, including organic fertilizer, compound fertilizer, and bulk raw materials. Large or caked materials are first fed into the system, where they are crushed into smaller, uniform particles. The processed material is then automatically conveyed to the next stage, such as mixing, granulating, or packaging.

This integrated design minimizes material handling steps, reduces dust pollution, and ensures continuous and stable operation. It is widely used in fertilizer production plants, agricultural processing facilities, and related industries.

Model	YSX70
Capacity (tons/hour)	30–40
Type	Trailer-mounted
Number of Hammers/Blades	20 Hammers, 60 Blades
Crushing Mechanism	Hammers / Blades
Standard Power Configuration	4102 Diesel Engine / 30 kW Electric Motor
Chamber Dimensions	0.65 × 0.65 m
Hopper Dimensions	3.4 × 1.5 m
Overall Dimensions	11.5 × 1.8 × 3.5 m
Feeding Height	2.5 m
Discharge Height	3.5 m
Rotor Weight (kg/piece)	5
Feeding Method	70 cm Belt Feeder
Discharge Method	70 cm Belt Conveyor

The fertilizer feeding, crushing, and conveying integrated machine operates through a continuous and automated process that combines three main stages: feeding, crushing, and conveying.

First, bulk or caked fertilizer materials are fed into the machine through the feeding system, which ensures a stable and controlled input. The materials then enter the crushing unit, where they are broken down into smaller, uniform particles by high-speed rotating blades or rollers.

After crushing, the processed materials are immediately transferred to the conveying system. Through a belt conveyor or screw conveyor, the materials are transported to the next stage of production, such as mixing, granulation, or packaging.

The entire process is carried out in a closed and coordinated system, which reduces material loss, minimizes dust generation, and ensures efficient and continuous operation.

Integrated feeding, crushing, and conveying functions
High efficiency and continuous operation
Suitable for various fertilizer materials
Compact structure and space-saving design
Reduced labor intensity and operating costs
