Organic and NPK fertilizer making machines

Automatic Palletizer

Power: 4 kw

Capacity: 500 bag/hour

Dimension: 3200*2200*3000 mm

Email: info@sxfertilizermachine.com
Mob & whatsapp: +86 15981847286
Tel: +86 371-86582811

Product Details

Automatic palletizer is a kind of automatic palletizing equipment. The flexible and fast stacking
method is an intelligent device that replaces manual palletizing. It can greatly improve work efficiency,increase the degree of mechanization and automation of palletizing, and is suitable for large-volume packaging palletizing production lines.
The working principle of the organic fertilizer automatic palletizer is that the workpiece on the flat
plate meets the requirements of the pallet, and the flat plate and the workpiece move forward until the vertical plane of the pallet. The upper stopper lever is lowered, and the other three positioning stopper levers are started to clamp. At this time, the plate is reset. Each workpiece is lowered to the plane of the pallet, and the plane of the pallet is 10mm away from the bottom surface of the plate. The pallet is lowered by one workpiece height. Re peat the above until the pallet stacking reaches the set requirements.

Working Video
